本章介绍 Web 后端开发中数据持久化技术 TKMyBatis。

TKMyBatis简介

TKMybatis 是基于 Mybatis 框架开发的一个工具，内部实现了对单表的基本数据操作，只需要简单继承 TKMybatis 提供的接口，就能够实现无需编写任何 sql 即能完成单表操作。

下面简单介绍下 MyBatis ， MyBatis 是一款优秀的持久层框架，它支持自定义 SQL、存储过程以及高级映射。MyBatis 免除了几乎所有的 JDBC 代码以及设置参数和获取结果集的工作。MyBatis 可以通过简单的 XML 或注解来配置和映射原始类型、接口和 Java POJO（Plain Old Java Objects，普通老式 Java 对象）为数据库中的记录。

详细内容请参考 https://mybatis.org/mybatis-3/zh/index.html

TKMyBatis快速开始

在实体类中，常用的注解和意义为：
Table：描述数据库表信息，主要属性有 name(表名)、schema、catalog、uniqueConstraints 等。
Id：指定表主键字段，没有属性值。
Column：描述数据库字段信息，主要属性有 name(字段名)、columnDefinition、insertable、length、nullable(是否可为空)、precision、scale、table、unique、updatable 等。

ColumnType：描述数据库字段类型，可对一些特殊类型作配置，进行特殊处理，主要属性有 jdbcType、column、typeHandler 等。

• 创建业务 Mapper 公共接口
• 首先创建一个公共接口，继承 Mapper, MySqlMapper, IdsMapper 三个类，用于后续业务 Mapper 接口直接实现。
• 1

• import tk.mybatis.mapper.common.IdsMapper;
• import tk.mybatis.mapper.common.Mapper;
• import tk.mybatis.mapper.common.MySqlMapper;
  public interface MySqlExtensionMapper extends Mapper, MySqlMapper, IdsMapper {
  }

import com.hogwartsmini.demo.common.MySqlExtensionMapper;
import com.hogwartsmini.demo.entity.HogwartsTestUser;
import org.springframework.stereotype.Repository;

@Repository
public interface HogwartsTestUserMapper extends MySqlExtensionMapper {

spring:
application:
name: aitest
#数据库配置信息
datasource:
url: jdbc:mysql://localhost:3306/aitest_mini?allowMultiQueries=true&useUnicode=true&characterEncoding=UTF-8&serverTimezone=Asia/Shanghai
username: hogwarts
password: db@hogwarts
driver-class-name: com.mysql.cj.jdbc.Driver
mybatis:
mapper-locations: classpath:mapper/*.xml
type-aliases-package: com.hogwartstest.aitestmini.entity
configuration:
mapUnderscoreToCamelCase: true
logging:
level:
com.hogwartstest.aitestmini.dao: debug #打印sql

CREATE TABLE hogwarts_test_user (
id int NOT NULL AUTO_INCREMENT COMMENT ‘主键’,
user_name varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL COMMENT ‘用户名’,
password varchar(32) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci NOT NULL COMMENT ‘密码’,
email varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci DEFAULT NULL COMMENT ‘邮箱’,
auto_create_case_job_name varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci DEFAULT NULL COMMENT ‘自动生成用例job名称 不为空时表示已经创建job’,
start_test_job_name varchar(50) CHARACTER SET utf8mb4 COLLATE utf8mb4_general_ci DEFAULT NULL COMMENT ‘执行测试job名称 不为空时表示已经创建job’,
default_jenkins_id int DEFAULT NULL COMMENT ‘默认Jenkins服务器’,
create_time datetime NOT NULL COMMENT ‘创建时间’,
update_time datetime NOT NULL COMMENT ‘更新时间’,
PRIMARY KEY (id) USING BTREE
) ENGINE=InnoDB AUTO_INCREMENT=12 DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_general_ci ROW_FORMAT=DYNAMIC COMMENT=‘用户表’;

import com.hogwartsmini.demo.entity.HogwartsTestUser;
import com.hogwartsmini.demo.service.HogwartsTestUserService;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;

import java.util.List;

/**

• @Author tlibn
• • @Date 2020/7/16 17:14
• **/
• @Api(tags = “霍格沃兹测试学院-用户管理模块”)
• @RestController
• @RequestMapping(“hogwartsUser”)
• public class HogwartsTestUserDbController {
  @Autowired
  private HogwartsTestUserService hogwartsTestUserService;
  @ApiOperation(“用户注册”)
  @PostMapping(“register”)
  public HogwartsTestUser register(
  @RequestBody HogwartsTestUser hogwartsTestUser){
  return hogwartsTestUserService.save(hogwartsTestUser);
  }
  @ApiOperation(“用户信息修改接口”)
  @PutMapping()
  public HogwartsTestUser updateUserInfo(
  @RequestBody HogwartsTestUser hogwartsTestUser){
  return hogwartsTestUserService.update(hogwartsTestUser);
  }
  @ApiOperation(“根据用户id删除用户信息”)
  @DeleteMapping(“{userId}”)
  public Integer delete(@PathVariable(“userId”) Integer userId){
  return hogwartsTestUserService.delete(userId);
  }
  @ApiOperation(“根据用户名查询”)
  @GetMapping(“byName”)
  public List getByName(
  @RequestParam(“userName”) String userName){
  HogwartsTestUser hogwartsTestUser = new HogwartsTestUser();
  hogwartsTestUser.setUserName(userName);
  return hogwartsTestUserService.getByName(hogwartsTestUser);
  }

import com.hogwartsmini.demo.entity.HogwartsTestUser;

import java.util.List;

public interface HogwartsTestUserService {

import com.hogwartsmini.demo.dao.HogwartsTestUserMapper;
import com.hogwartsmini.demo.entity.HogwartsTestUser;
import com.hogwartsmini.demo.service.HogwartsTestUserService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

import java.util.Date;
import java.util.List;

/**

• @Author tlibn
• • @Date 2020/7/17 11:03
• **/
• @Service
• public class HogwartsTestUserServiceImpl implements HogwartsTestUserService {
  @Autowired
  private HogwartsTestUserMapper hogwartsTestUserMapper;
  /**
  * 保存
  * *
  * * @param hogwartsTestUser
  * * @return
  * /
  * @Override
  * public HogwartsTestUser save(HogwartsTestUser hogwartsTestUser) {
  * hogwartsTestUser.setCreateTime(new Date());
  * hogwartsTestUser.setUpdateTime(new Date());
  * hogwartsTestUserMapper.insertUseGeneratedKeys(hogwartsTestUser);
  * return hogwartsTestUser;
  * }
  /*
  * 更新
  * *
  * * @param hogwartsTestUser
  * * @return
  * /
  * @Override
  * public HogwartsTestUser update(HogwartsTestUser hogwartsTestUser) {
  * hogwartsTestUser.setCreateTime(new Date());
  * hogwartsTestUser.setUpdateTime(new Date());
  * hogwartsTestUserMapper.updateByPrimaryKeySelective(hogwartsTestUser);
  * return hogwartsTestUser;
  * }
  /*
  * 根据用户名查询
  * *
  * * @param hogwartsTestUser
  * * @return
  * /
  * @Override
  * public List getByName(HogwartsTestUser hogwartsTestUser) {
  * List hogwartsTestUserList = hogwartsTestUserMapper.select(hogwartsTestUser);
  * return hogwartsTestUserList;
  * }
  /*
  * 根据用户id删除用户信息
  * *
  * * @param userId
  * * @return
  * */
  * @Override
  * public Integer delete(Integer userId) {
  * HogwartsTestUser hogwartsTestUser = new HogwartsTestUser();
  * hogwartsTestUser.setId(userId);
  * hogwartsTestUserMapper.delete(hogwartsTestUser);
  * return userId;
  * }
  * }

响应参数

• 查询
• GET http://127.0.0.1:8081/hogwartsUser/byName?userName=霍格沃兹test123
• 请求参数

响应参数

• 修改
• PUT http://127.0.0.1:8081/hogwartsUser
• 请求参数
• 1

• {
• “id”: 15,
• “userName”: “霍格沃兹test12345”,
• “password”: “test123”
• }

{
“id”: 15,
“userName”: “霍格沃兹test12345”,
“password”: “test123”,
“email”: null,
“autoCreateCaseJobName”: null,
“startTestJobName”: null,
“defaultJenkinsId”: null,
“createTime”: “2021-04-14T09:43:45.018+00:00”,
“updateTime”: “2021-04-14T09:43:45.018+00:00”
}

见请求地址中15
